In the realm of construction, finding the right structural solution is crucial for ensuring the safety, strength, and efficiency of a building. One such versatile and reliable option gaining popularity in recent years is the use of pipe trusses. These trusses, constructed from interconnected pipes, offer numerous advantages in terms of strength, flexibility, and cost-effectiveness. In this article, we will explore the concept of pipe trusses, their applications, and the benefits they bring to construction projects.

Advantages of Tubular Truss Steel Structure: Compared with space truss structure, pipe truss structure eliminates vertical bar and space truss bottom chord node, which can meet the requirements of various architectural forms, especially arch and arbitrary curved shape construction is more advantageous than space truss structure. Its stability is different and material consumption is saved. The steel pipe truss structure is developed on the basis of lattice structure, which has its unique superiority and practicality compared with lattice structure. The steel self-weight of the structure is more economical. Compared with traditional open section (H-steel and I-steel), the steel truss pipe truss structure section material is evenly distributed around the neutral axis, and the section has good compressive and bending bearing capacity and large stiffness at the same time. There is no node plate, the structure is simple, and the most important thing of the pipe truss structure is that it is beautiful, easy to shape and has certain decorative effect. The overall performance of the pipe truss structure is good, torsional stiffness is large, beautiful and generous, easy to make, install, flip, hoist; using cold-bent thin-walled steel pipe truss, light weight, good rigidity, save steel structure, and can fully play Read more

Roofing Systems: Pipe trusses are commonly used as roofing systems in commercial, industrial, and even residential buildings. The triangular or quadrilateral shape of the trusses provides excellent load-bearing capacity, allowing for large spans without the need for intermediate supports. This design feature creates expansive interior spaces and facilitates efficient use of the building.

Pipe trusses, also known as tubular trusses, are structural frameworks composed of interconnected pipes. These trusses form a triangular or quadrilateral shape to provide stability and distribute loads evenly, allowing for the construction of large and complex structures. The pipes used in pipe trusses are typically made of steel or aluminum due to their high strength-to-weight ratio and durability.

These Aluminum Bolt Square Truss are always used as background frame and for light lighting .Connect each truss with pin part and easy to set up .Length or thickness can be customized according to customer's requirement. Truss Material Aluminum alloy 6082-T6 Light duty truss 200*200mm   220*220mm Medium duty truss 290*290mm 300*300mm 350*350mm 400*400mm  450*450mm 400*600mm Heavy duty truss 520*760mm  600*760mm  600*1100mm Main tube thickness Ø30*2mm Ø50*3mm Ø50*4mm Vice tube thickness Ø20*2mm Ø25*2mm Ø30*2mm Brace tube thickness Ø20*2mm Ø25*2mm Ø30*2mm Truss length 0.5m / 1m / 1.5m / 2m / 3m / 4m or customized Truss type Spigot or Bolt Truss shape Ladder , Triangular, Square, Rectangle,Arc, Circle,irregular shapes Optional color Silver / Black / Blue or customized Application Booth, fashion show, catwalk, wedding, new product release, concert, ceremony, party, etc. Delivery time 5-15 days   300mm x 300mm Spigot Truss Load Table Span (M) 2M 3M 4M 5M 6M 8M 10M 12M 14M Center Point Load            (KGS) 890 780 680 600 470 390 290 210 160 Deflection                  (MM) 5 8 13 13 16 29 45 62 88 DistributeLoad               (KGS) 1630 1530 1430 1330 1230 930 730 630 530 Deflection                  (MM) 4 12 23 36 48 75 97 138 165   400mm Read more

Large Span Prefabricated Building Metal Frame Shed Warehouse Steel Structure ,Steel material Structural steel Q235B, Q345B, or others as buyers' requests. Purlin C or Z purlin: Size from C120~C320, Z100~Z20 Bracing X-type or other type bracing made from angle, round pipe
